Automatic Wooden Mop Handle Head Threading Machine
Automatic Wooden Mop Handle Head Threading Machine is used to make a screw thread on wood round rod head. This Wooden Rod Threading Machine makes it more convenient to install and screw mop, broom, shovel, farm tools, etc. It can cut all wood rod handle two sides and make the wooden round rod to be standard length to make one side to be thread(screw) and another side to being the round head.
Specification of Broom Wooden Handle Head Threading Machine
| Axscrew thread journey | 28mm |
| Working length | 800-1300mm/1200-1500mm |
| Max. screw-pitch | 6mm |
| Min.screw-pitch | 3mm |
| Machine size | 2400*1200*1100mm |
| Machine weight | 1100kg |
| Feeding motor power | 0.55kw |
| Milling alter power | 0.75kw |
| Feeding speed | 20-25 sticks/min |
| Working diameter | 18-30mm(or)30-38Â mm |
Working Video of Wood Broom Handle Head Threading Machine
